Heliflex® AT™-5ms



• Similar to DB-5ms, Rtx®-5 Sil ms,
HP-5TA, BPX™-5, 007-5ms
The AT™-5ms capillaries are ideal for environmental,
pharmaceutical, and petrochemical analysis, or any GC/MS
analysis requiring a 5% phenyl-type polarity capillary column.





Heliflex® AT™-5ms Specifications
Phase: (5% Phenyl)-95% Methoxpolysiloxane
Polarity: Non-polar
USP Designation: G27, G36
Ideal For: Mass Spec Analysis—General Application



Heliflex (R) AT(tm) - 5ms









Length
i.d.
Film
Temp. Limits
min.–max.
Part Number
15m
0.25mm
0.25μm
-60–325/350°C
15801
30m








0.25mm
0.10μm
-60–325/350°C
15806
0.25mm
0.25μm
-60–325/350°C
15807
0.25mm
0.25μm
-60–325/350°C
15881*
0.25mm
0.50μm
-60–325/350°C
15808
0.25mm
0.50μm
-60–325/350°C
15889*
0.25mm
1.00μm
-60–325/350°C
15809
0.32mm
0.25μm
-60–325/350°C
15894
0.32mm
0.25μm
-60–325/350°C
15883*
0.32mm
1.00μm
-60–325/350°C
15895
60m



0.25mm
0.10μm
-60–325/350°C
15879
0.25mm
0.25μm
-60–325/350°C
15891
0.25mm
1.00μm
-60–325/350°C
15892
0.32mm
0.25μm
-60–325/350°C
15896


*Isothermal/Temp. program.
