SGE Capillary Columns

BPX70- 70% Cyanopropyl Polysilphenylene-Siloxane





ID(mm)	Length (m)	Film Thickness (µm)	Temperature Limits (°C)	Part No.
0.10	10	0.20	50 to 250/260	054600
0.22	12	0.25	50 to 250/260	054601
	25	0.25	50 to 250/260	054602
	30	0.25	50 to 250/260	054612
	50	0.25	50 to 250/260	054603
	60	0.25	50 to 250/260	054613
0.25	15	0.25	50 to 250/260	054621
	30	0.25	50 to 250/260	054622
	60	0.25	50 to 250/260	054623
	120	0.25	50 to 250/260	054624
0.32	17	0.25	50 to 250/260	054605
	25	0.25	50 to 250/260	054606
	30	0.25	50 to 250/260	054616
	50	0.25	50 to 250/260	054607
	60	0.25	50 to 250/260	054617
0.53	15	0.50	50 to 250/260	054619
	25	0.50	50 to 250/260	054610
	30	0.50	50 to 250/260	054620











BPX70 Capillary Columns



* Highest Temperature polar column available

* Custom designes for seperation of Fatty Acid Methyl Esters (FAMEs)

* Industry standard column for FAME analysis

* Ideal for cis/trans isomer seperation

* Suitable upgrade from DB-23, CP-Sil 88, VF-23ms, SP-2330, SP-2380, Rtx®-2330, 007-23, AT-Silar & PE-23
