Type
|
Order
Number
|
Optical Fibre
Connector
|
661.682-UV *
|
661682-V1-M1-UV-2m-46
|
SMA
Collimators for Fibre-
Optic Cable Interface
|
| |
|
|
| |
|
|
661.682-NIR *
|
661682-V1-M1-NIR-2m-46
|
SMA
Collimators for Fibre-
Optic Cable Interface
|
| |
|
| |
|
Mirror material**
|
Quartz glass SUPRASIL® 300
with aluminium reflective layer
|
| |
|
| |
|
Window material**
|
Quartz glass SUPRASIL® 300
|
| |
|
| |
|
Probe barrel material***
|
Stainless steel 1.4435 (316L)
|
| |
|
| |
|
Probehead seal
|
Perfluorelastomer FFKM (ASTM 01418)
|
| |
|
| |
|
Outer Ø
|
12 mm
|
| |
|
| |
|
Total length
|
260 mm
|
| |
|
| |
|
Max. immersion depth
|
215 mm
|
| |
|
| |
|
Removable tips
|
Typ 665.764
|
| |
|
| |
|
Max. pressure
|
15 bar
|
| |
|
| |
|
Max. temperature
|
180 °C
|
| |
|
| |
|
Optical fibre connections
|
FSMA Typ 905
|
| |
|
| |
|
Optical fibres****
|
Built in, not exchangeable
UV
Length: 1,8 m
240 nm – 1100 nm (41667 cm-1 – 9100 cm-1)
NIR
Length: 1,8 m
400 nm – 2300 nm (25000 cm-1 – 4348 cm-1)
UV/Vis and UV/Vis low solarisation upon request
|
